High Forming Speed Roof Tile Making Machine with Mitsubishi Technology PLC Automatic Control
XD-E full automatic mgo roof tile making machine with 1200 shees
Automatic operation roof Tile Making Machinery with high quality
New type of cylindrical tile molding machine whit high forming speed, large output, and reliable performance. Using PLC (Mitsubishi technology) automatic control, hydraulic pneumatic, the speed of production can up to 6-9 pieces/ min, in a high yield, cost-effective priorities.
2. A new type of cylindrical molding machine, the underside of slid platform is made of semi-circular
guide rail, compared with the square guide rail more stable and more wear-resistant.
Main oil cylinder and four-cylinder overall orientation, not only to improve the stability of the equipment,
but also to extend the life of the mold.
3. Through the filter press type molding, product with beautiful structure, variety kinds, high density, strong strength, accurate size to meet the needs of various types of buildings are concrete products of quality
products.
4. A multi-purpose machine, by replacing the mold, can produce various types main tile and
matching tiles.
| Model | 125 tile forming machine |
| Overall Dimension | 3120*1750*2650 mm |
| Molding Cycle | 8-10 s |
| Molding Pressure | 1250 KN |
| Weight of Main Engine | 5.5 T |
| Equipped Capacitor | 16 kw |
| Production Capacity | 2000-3000 pcs/day |
| Tile Size | 424*337*10 mm |
Color Steel Roof Panel Tile Cold Roll Forming Machine / Making Machine
We are the professional color steel sheet cold roll forming machine manufacturer in China.
Roll Forming Machine is made of feeding section, forming section and punching & cutting section, the finished profiles are flat and beautiful and high strength and durable. The finished profiles are widely used in construction sites, workshop, warehouses and so on.
Our machine features high durability and good appearance. Welcome to inquiry our machines, we will offer the lower price and better delivery time.
2. Raw material and cost analysis
The product is formed with crushed crop straw or sawdust and some inorganic
chemical materials at one time after roller-extruding. The source of raw materials is widely and they are purchased easily
for customers.
Take specification of 1.22mX2.44mX3mm as example, the cost is 7~8 Yuan, and
the market price is generally 13~16 Yuan.
3. Technology features
There is not any requirement about high temperature and high pressure during
production processing. The board will be formed at one time after roller-extruding under the conditions of normal temperature and normal pressure. This
is a green environmental-protection project, because that there is no waste water, waste materials and waste
gas during its production processing. The finished board don't need high
temperature drying, air-drying and watering, and under the normal temperature,
they will dry well indoor.
